Return air primary filter

It can be used for pre-filtration and secondary filtration in air conditioning and ventilation systems, and for filtering the inlet or return air in clean rooms.

Size:

Customized According to Drawing

Samples:

Support Sample Making

Transport Package:

Polybag, Carton, Wooden Case etc

Specification:

Accept Custom Development

Trademark:

HAIBEIJING

Origin:

Guangdong Haibei Purification Technology Co., Ltd.

INQUIRE NOW

Product Description

haibeijing filter.png

aluminum paint air filters.jpg

Characteristic

High air flow rate, low initial pressure drop, high dust holding capacity, long operating life
The material is the coarse efficiency filter media with metal frame
Easy assembly in air conditioning equipment
Good ventilation property, small resistance
Temperature resistance 80°C

SPECIFICATIONS：

Filtration Grade	Dimensions (mm) WH D	Initial Resistance (Pa)	Final Resistance (Pa)	Rated Air Flow (m³/h)
G3	59559520	35	120	1900
G3	29059520	35	120	1000
G3	59559546	35	120	3400
G3	29059546	35	120	1700
G4	59559525	45	150	1900
G4	29059525	45	150	1000
G4	59559546	45	150	3400
G4	29059546	45	150	1700

Filter Customization：

Explore our full range of air filters and find the perfect solution for your needs. Please send us your requirements to get custom sizes and thicknesses.
